Danfoss Thermostat DEVIreg TOUCH PURE BLACK

In Stock

Other people want this. 4 people have this in their carts right now.

Description

Gross weight	0.242 Kg
Net weight	0.24 Kg

Volume	1.131 Liter
EAN	5703466225608

1 Primary battery SUM weight Kg	0
1 Primary battery weight Kg	0
2-pole switch	No
Ambient temperature [°C] [max]	30 °C
Ambient temperature [°C] [min]	0 °C
Application	Floor heating
Approval	UkrTEST CE
Ball pressure test temperature [°C]	75 °C
Battery backup	Yes
Battery qty	1
Battery type or Name	Knapcelle Manganese Lithium
Certification company	CE EAC Intertek Semko UkrTEST
Colour	Black RAL 9005
Compatible foreign sensor type	Yes
Compatible frame system	Yes
Depth [mm]	24 mm
Description	DEVIreg™ Touch – Pure Black
DIN mounting	No
Display (Yes/No)	Yes
Display type	Touch screen
Element IP Class	21
Frost protection [°C]	5 °C
Height [mm]	85 mm
In scope of WEEE and contain batteries	Yes
Inductive load	cos φ= 0.3 max 1A
Package depth [mm]	140 mm
Package height [mm]	85 mm
Package width [mm]	95 mm
Pollution degree	2
Product description	DEVIreg™ Touch Pure Black
Product group	Thermostats

REACH Candidate List substances	No
Regulation type	PWM
Relay switch	1-pole
Resistive load max [A]	16 A
Sensor definition point [Ohm/°C]	15kΩ / 25°C
Sensor type	Room + Floor
Software class	A
Standby power consumption [W] [Max]	0.4 W
Storage temperature [°C] [Max]	65 °C
Storage temperature [°C] [Min]	-20 °C
Supply voltage [V] AC	230 V
Supply voltage [V] AC [max]	240 V
Supply voltage [V] AC [min]	220 V
Temperature – floor [°C] [Max]	45 °C
Temperature – floor [°C] [Min]	5 °C
Temperature – room [°C] [Max]	35 °C
Temperature – room [°C] [Min]	5 °C
Temperature limiter [°C] [Max]	45 °C
Temperature limiter [°C] [Min]	5 °C
Temperature max. limiter [°C] [Max]	35 °C
Temperature max. limiter [°C] [Min]	20 °C
Temperature min. limiter [°C] [Max]	35 °C
Temperature min. limiter [°C] [Min]	10 °C
Terminal cable size max [mm²]	2 x 2.5
Thermostat IP Class	21
Type	DEVIreg™ Touch
UNSPSC CODE	41112209
Warranty [Year]	5
Warranty type	5-year product warranty
Weight per battery	0 g
Width [mm]	85 mm
